2026 Fox 36 FLOAT E-Optimized Kashima Factory Suspension Fork – 29in, 160mm, Kabolt X 110, 44mm Offset, 58HT, Shiny Black, Grip X

Since its debut in 2005, the FOX 36 has set the benchmark for single-crown forks, delivering best-in-class performance with an unmatched stiffness-to-weight ratio. In its latest evolution, the 36 raises the bar even further for All-Mountain dominance, while the all-new 36 SL brings lightweight performance to aggressive Trail riders. With redesigned chassis, increased bushing overlap, andthe innovative new compliant FLOATGlidecore air springs, both forks push the limits of stiffness, smoothness, and responsiveness in their respective categories.

Fox 36: The Apex of All-Mountain

All-mountain riders are pushing their bikes harder than ever, driven by advancements in frame design, components, and tire technology. With the new 36, we set out to elevate the performance of these boundary-pushing bikesdelivering a fork that not only meets but exceeds the demands of modern riders. The new 36 combines the confidence-inspiring Enduro feel of the 38 with a category-optimized design thats lightweight, responsive, and playful.

Key Innovations:

• New 36 Chassis 20% greater torsional stiffness over the previous model, approaching the steering precision of the FOX 38.
• Arch Optimization Generatively designed, the new 36 arch enhances torsional stiffness while strategic cutouts minimize weight and refine aesthetics.
• FLOAT Glidecore Ultra-Low-Friction CompliantAir Spring A completely new design with a floating air spring core that decouples the stanchion from the air shaft to maintain smooth travel even under bending loads from speed or rider weight. This gives riders a supple and planted feeling when they need it most.
• Increased Bushing Overlap 30mm of additional bushing overlap significantly reduces friction, providing a smoother feel, especially on rough terrain.
• GRIP X2 Damper More traction, more control, more speed. The refined 4-way tunable GRIP X2 damper provides increased adjustability while maintaining minimal cross-talk between settings.
• GRIP X Damper A lightweight, easy-to-tune alternative to GRIP X2, delivering a balance of descending capability and efficient pedaling performance.
• Inboard Bypass Channels Relocated from the aft side to the inboard side, these channels enhance small bump sensitivity, reduce pressure buildup, and improve overall suspension response.
• Low-Profile Bleeders Redesigned with a grooved structure for easier pressure equalization.
• Air Spring Top Cap Now compatible with a standard Shimano cassette tool for simple volume adjustments.
• Refined Mudguard Mounting Mounted to the arch and seal flanges instead of bleeder ports for improved durability and aesthetics.

Big Fork Energy, Without the Weight
Riders seeking uncompromised stiffness, precision handling, and a remarkably smooth ride need look no further. The FOX 36 continues its reign as the apex of All-Mountain ridingstiffer, smoother, and more capable than ever.

Specifications:

• Wheel Size:29, 27.5
• Travel:140mm, 150mm, 160mm
• Rake:37mm, 44mm (27.5); 44mm (29)
• Axle:Kabolt, 15QR on Performance Series
• Rotor Size:Direct Mount 200, up to 230
• Air Spring:FLOAT EVOL Compliant
• Steerer:1.5 Tapered
• Starting Weight: 1920g (29 160mm GRIP X)
